Oracle Server X5-8 - Full Components List
Table Legend
[F] = Field Replaceable Unit (FRU)
[C] = Customer Replaceable Unit (CRU)
[A] = Alternate, can be used in system; wasn't used during production
[S] = Supported, but can no longer be ordered with this system
[N] = No longer supported for this system
Price = Price this Part
Backplane/Centerplane
Option #
Manufacturing
Description
Previous
n/a
7308647 [F]
Busbar/Midplane Assembly
n/a
n/a
n/a
8-Slot Midplane Subassembly n/a
n/a
Batteries
Option #
Manufacturing
Description
Previous
n/a
150-3993
[C] Buy
3V Lithium Coin Cell Battery
n/a
CPU Module
Option #
Manufacturing
Description
Previous
n/a
7080100 [F]
CPU Heatsink
n/a
n/a
7080240
CPU Installation/Removal Tool
n/a
n/a
7302593
[F]
18-Core 2.6GHz Intel E7-8895 v3, 175W
n/a
n/a
7304446 [F]
CPU/Memory Module Assembly
n/a
n/a
n/a
n/a
Cables
Option #
Manufacturing
Description
Previous
7102869 Buy
7039990 [C]
MPO to MPO High Bandwidth QSFP Optical Cable, 10M
n/a
7102870 Buy
7039999 [C]
MPO to MPO High Bandwidth QSFP Optical Cable, 20M
n/a
7102871 Buy
7040001 [C]
MPO to MPO High Bandwidth QSFP Optical Cable, 50M
n/a
X2121A-1M-N Buy
530-4444 [C]
10Gbps QSFP to QSFP Cable, 1m
n/a
X2121A-2M Buy
530-4567 [C]
10Gbps QSFP to QSFP Cable, 2m
n/a
X2121A-3M-N Buy
530-4445 [C]
10Gbps QSFP to QSFP Cable, 3m
n/a
X2121A-5M-N Buy
530-4446 [C]
10Gbps QSFP to QSFP Cable, 5m
n/a
X2125A-1M-N Buy
530-4450 [C]
QSFP to 4× SFP+ Splitter Cable, 1m
n/a
X2125A-3M-N Buy
530-4451 [C]
QSFP to 4× SFP+ Splitter Cable, 3m
n/a
X2125A-5M-N Buy
530-4452 [C]
QSFP to 4× SFP+ Splitter Cable, 5m
n/a
X2127A-10M Buy
530-4480 [C]
MPO to 4x LC Duplex Splitter Cable, 10m
n/a
X2127A-20M Buy
530-4481 [C]
MPO to 4x LC Duplex Splitter Cable, 20m
n/a
X2127A-50M Buy
530-4482 [C]
MPO to 4x LC Duplex Splitter Cable, 50m
n/a
n/a
530-3100
RJ45F to DB9F Adapter
n/a
n/a
7084503 [C]
Cable Kit
n/a
n/a
n/a
n/a
n/a
7096698 [F]
2x 36-Pin SFF-8643 to 72-Pin SFF-8643 SAS-3 Cable, 300mm
n/a
Chassis
Option #
Manufacturing
Description
Previous
n/a
7098401
Chassis Assembly
n/a
n/a
n/a
n/a
n/a
Power Supply Cable Assembly n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
n/a
7343407
Chassis Subassembly
7054505
n/a
n/a
n/a
n/a
Power Supply Cable Assembly n/a
n/a
n/a
n/a
n/a
n/a
Communication
Option #
Manufacturing
Description
Previous
7104074 Buy
7092757
[C]
Dual 40Gb/Sec (4x) QDR InfiniBand Host Channel Adapter Module M3
7046442
[C]
n/a
7046442
[C]
Dual 40Gb/Sec (4x) QDR InfiniBand Host Channel Adapter Module M3
n/a
Disks
Option #
Manufacturing
Description
Previous
7110933 Buy
7094132 [C]
400GB Solid State SAS Drive Assembly
n/a
400GB SAS Solid State Drive [HSCAC2DA4SUN400G] n/a
n/a
7111103 Buy
7093015 [C]
600GB - 10000 RPM SAS Disk Assembly with 1 bracket and 1 of the following disks:
n/a
Hitachi HUC101860CSS200 [H101860SFSUN600G] (600.0GB - 10000 RPM SAS Disk) n/a
n/a
7111108 Buy
7093037 [C]
1.2TB - 10000 RPM SAS SFF Disk Assembly w 1 bracket and 1 of the following disks:
n/a
Hitachi HUC101812CSS200 [H101812SFSUN1.2T] (1.2TB - 10000 RPM - SAS DISK) n/a
n/a
n/a
7350749 [C]
800GB SAS3 Solid State Disk Assembly without Encryption (EAEU part - see note below)
n/a
HGST HUSMM3280ASS204 [HBSAC2DH4SUN800G] (800GB - 2.5" Solid State - SAS3 Disk without Encryption) (EAEU part - see note below) n/a
n/a
n/a
7350766 [C]
1.2TB - 10000 RPM SAS Disk Assembly without Encryption (EAEU part - see note below)
n/a
HGST HUC101812CSS204 [H1018124FSUN1.2T] (1.2TB - 10000 RPM SAS Disk without Encryption) (EAEU part - see note below) n/a
n/a
n/a
7352257 [C]
600GB - 10000 RPM SAS Disk Drive Assembly without Encryption (EAEU part - see note below)
n/a
HGST HUC101860CSS204 [H1018604FSUN600G] (600GB - 10000 RPM SAS Disk without Encryption) (EAEU part - see note below) n/a
n/a
Ethernet
Option #
Manufacturing
Description
Previous
7100477 Buy
7070195
[C]
Quad Port GbE PCI Express 2.0 Low Profile Adapter, UTP
n/a
7100488 Buy
7070006
[C]
Dual 10-Gigabit Base-T PCI Express Gen2
n/a
7111181
7096675
[C]
Quad 10-Gigabit Base-T Ethernet
n/a
X1109A-Z Buy
7051223
[C]
Dual 10-Gigabit PCI Express Ethernet SFP+ LP
n/a
X2129A-N Buy
530-4449
[C]
10Gb/Sec Short Wave SFP+ Transceiver
n/a
X5562A-Z Buy
135-1205
[C]
10Gb/Sec Long Wave SFP+ Transceiver
n/a
X2124A
[S]
7326504
[C]
10Gbps QDR InfiniBand/40Gbps Ethernet QSFP Transceiver
135-1204
[C]
n/a
135-1204
[C]
10Gb/Sec QDR InfiniBand / 40Gb/Sec Ethernet QSFP Transceiver
n/a
Fan
Option #
Manufacturing
Description
Previous
n/a
7091709
Fan Frame
n/a
n/a
7091860 [C]
Fan Module, 80x76mm, 13000 RPM
n/a
80x76mm Dual Counter Rotating Fan, 13500/11600 RPM n/a
Fibre Channel
Option #
Manufacturing
Description
Previous
7101674 Buy
7023303
[C]
Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, QLogic
n/a
7101676 Buy
7023325
[C]
Pair of 16Gbps Short Wave SFP+
n/a
16Gb/Sec Short Wave SFP+ Transceiver, QLogic n/a
7101678 Buy
7023315
[C]
Pair of 10Gbps Short Wave SFP+
n/a
10Gb/Sec Short Wave SFP+ Transceiver, QLogic n/a
7101680 Buy
7023066
[C]
Pair of 16Gbps Long Wave SFP+
n/a
16Gb/Sec Long Wave SFP+ Transceiver, QLogic n/a
7101684 Buy
7023036
[C]
Dual 16Gigabit/Sec Fibre Channel / 10Gbps FCoE Host Adapter, Emulex
n/a
7101686 Buy
7023059
[C]
Pair of 16Gbps Short Wave SFP+
n/a
16Gb/Sec Short Wave SFP+ Transceiver, Emulex n/a
7101688
[S]
7023057
[C]
Pair of 10Gbps Short Wave SFP+
n/a
10Gb/Sec Short Wave SFP+ Transceiver, Emulex n/a
I/O
Option #
Manufacturing
Description
Previous
n/a
351-0009
PCI Express Filler Panel, Low Profile
n/a
n/a
7084488
[F]
Front Indicator Module (FIM)
n/a
n/a
n/a
n/a
n/a
Front Circuit Board, FIM1 n/a
n/a
7094766 [C]
Dual PCI Express Card Carriers (DPCC)
n/a
n/a
n/a
Memory
Option #
Manufacturing
Description
Previous
7111365
[S]
7095790
[C]
16GB DDR3L-1600 1.35V Registered DIMM
n/a
7111372
[S]
7095791
[C]
32GB DDR3L-1600 1.35V Load Reduced DIMM
n/a
n/a
7090170
[C]
8GB USB Stick
n/a
Power
Option #
Manufacturing
Description
Previous
n/a
7081596
[C]
Type A261 3000 Watt AC Input Power Supply
n/a
n/a
7302922
[C]
Type A261 3000 Watt AC Input Power Supply
7081596
[C]
n/a
7335848
[C]
Type A261 3000 Watt AC Input Power Supply - India ISI Mark
7302922
[C]
+
n/a
7352331 [C]
Type A261 3000W AC Input Power Supply
n/a
Rack
Option #
Manufacturing
Description
Previous
n/a
7090552 [C]
Rackmount Kit
n/a
n/a
n/a
SCSI
Option #
Manufacturing
Description
Previous
7113826 Buy
7317693
[C]
3.2TB Flash Accelerator F320 NVMe Card
n/a
7110865
[S]
7307468
[C]
1.6TB Flash Accelerator F160 NVMe Card w/ LP Bracket (B1 Silicon)
n/a
n/a
7085211
Internal RAID HBA Assembly
n/a
Double Sided Fastener, 1"x5" n/a
8-Port 12Gbps SAS3 Internal RAID HBA n/a
13.5V 6.4F Super Capacitor n/a
n/a
System Board
Option #
Manufacturing
Description
Previous
n/a
7096849 [F]
System Module Assembly (SMOD)
n/a
4-Slot Disk Cage Assembly n/a
n/a
n/a
n/a
System Module Controller Subassembly n/a
System Module PCI Express Riser n/a
n/a
3V Lithium Coin Cell Battery
n/a
Table Legend
[F] = Field Replaceable Unit (FRU)
[C] = Customer Replaceable Unit (CRU)
[A] = Alternate, can be used in system; wasn't used during production
[S] = Supported, but can no longer be ordered with this system
[N] = No longer supported for this system
Price = Price this Part
Table Legend
[F] = Field Replaceable Unit (FRU)
[C] = Customer Replaceable Unit (CRU)
[A] = Alternate, can be used in system; wasn't used during production
[S] = Supported, but can no longer be ordered with this system
[N] = No longer supported for this system
Price = Price this Part
NS = Not Shown
Code
Manufacturing Part#
Description
NS
541-2629
2.5" Disk Drive Filler Panel
NS
