10Gigabit/Sec Short Wave SFP+ Transceiver

Option X2129A
Option X5561A-Z
Option 7101678
Option 7101688
Option SG-XSWBROSFP10GES1
Option SG-XSWBROSFP10GES8

135-1196	373-0482	530-4449
10Gbps 10GBASE-SR Avago AFBR-700SDZ-SN JDSU PLRXPL-SC-S43-21-N Option X5561A-Z	manufacturer unknown sourced from Brocade SG-XSWBROSFP10GES1 SG-XSWBROSFP10GES8 [S]	10Gbps 10GBASE-SR 1Gbps 1000BASE-SX Avago AFBR-703SDDZ-SX* Avago AFBR-709DMZ-SX Avago AFBR-709DMZ-SN1 Finisar FTLX8571D3BCV* Finisar FTLX8571D3BCV-SU* Finisar FTLX8574D3BCV-SU X2129A / X5561A-Z * - See X7-2 / X7-2L notes below

7023046	7023316	7043788	7063112
manufacturer unknown sourced from Emulex FRU Pair 7023057 Option 7101688	manufacturer unknown sourced from QLogic FRU Pair 7023315 Option 7101678	manufacturer unknown sourced from Brocade Option 7103545 [S]	10Gbps Short Wave SFP+ Finisar FTLX8571D3BCL JDSU PLRXPL-SC-S43-22-N

Table Legend

[S] = Supported but can no longer be ordered

Table Legend

[S] = Supported but can no longer be ordered

Notes

1. AFBR-700SDZ-SN is a Sun Microsystems version of AFBR-700SDZ.
2. PLRXPL-SC-S43-S1 is a Sun Microsystems version of PLRXPL-SC-S43-21-N.

X5561A-Z Notes

1. Option X5561A-Z was announced in August 2008.
2. SFP+ 135-1196 was released in May 2008. (AVL Change Request CW_22298)
3. SFP+ F135-1196 was released in June 2008. (WO_39461)
4. X5561A-Z changed from 135-1196 to 530-4449 in April 2010. (WO_42928)

X7-2 / X7-2L Notes

1. Avago AFBR-703SDDZ-SX does not fit correctly in X7-2 or X7-2L.
2. Finisar FTLX8571D3BCV and Finisar FTLX8571D3BCV-SU do not
   work in X7-2 or X7-2L, unless using Broadcom Firmware 20.6.4.7 or later.

3. GSAP 7113 purges AFBR-703SDDZ-SX.

7023046 and 7023316 Notes

1. Emulex is responsible for vendor qualification for SFP+ 7023046.
2. QLogic is responsible for vendor qualification for SFP+ 7023316.
3. Do not mix SFP+ transceivers using different vendor part numbers.
4. Options and FRU's include two SFP+ transceivers with the same vendor part number.
5. SFP+ 7023046 is Only for use in Emulex Host Adapter 7023036 and 7023043.
6. SFP+ 7023316 is Only for use in QLogic Host Adapter 7023303 and 7023304.
7. There are no qualified substitutions for 7023046 or 7023316.
