Front Indicator Module (FIM)

<a href="../../Systems/SupportHeaders/IO_X4_8_Front_Indicator_Module.html">Hmm, you are using a very old browser. Click here to go directly to included content.</a>

7057505 7082596 7084488 Rev02 7084488 Rev03

Rear Circuit Board FIM2
Fruid 7057505 Front Circuit Board FIM1
No Fruid FIM Assembly/FRU
FIM1 Assembly 7084487
FIM2 7057505
Cable 7074700 FIM Assembly/FRU
FIM1 Assembly 7098638
FIM2 7057505
Cable 7074700

Exploded Front View
