Ultra[tm] 1 Workstation Model 140E/170E/200E (A12) Netra i 1/170E / Netra i 1/200E

Premier Support End Date = June 2016
Follow this link to view Service Life End Dates.

2-Slot SBus Logic Enclosure (exploded)

300-1248 300-1308 180W Power Supply (obsolete) 180W Power Supply

CPU Board (Model 140E) 501-4291 501-4677

CPU Board (Model 170E) 501-2486 501-4676 FAB 270-2486-03 FAB 270-2486-04/05

CPU Board (Model 200E) 501-4134 501-4358 501-5403

Internal Peripherals

Memory Graphics Fibre Channel SCSI Disk Removable Media Ethernet Communication Miscellaneous IDPROM Boot PROM

	Description
Memory	16MB DIMM 64MB DIMM 32MB DIMM 128MB DIMM
	SBus Prestoserve
Graphics	ZX 24-Bit Color Frame Buffer
	SunVideo 501-2232 501-3019
	TurboGX 8-Bit Color Frame Buffer 501-2325 501-2922
	TurboGXplus 8-Bit Color Frame Buffer 501-2253 501-2955
	Creator Series 1 (FFB) 501-2634 501-4127
	Creator3D Series 1 (FFB) 501-2633 501-3129 501-4126
	Creator3D Series 2 (FFB2) 501-4173
Fibre Channel	Fibre Channel Host Adapter (FC25/S)
SCSI	SCSI (SSHA)
	SCSI/Ethernet (SBE/S)
	Fast SCSI/Ethernet (FSBE/S) 501-2015 501-2981
	Differential SCSI/Ethernet (DSBE/S)
	Single-Ended Wide SCSI (SWIS/S)
	Differential Fast/Wide SCSI (DWIS/S)
	Ultra Differential Fast/Wide SCSI (UDWIS/S)
	Single-Ended Fast/Wide SCSI/FastEthernet (SunSwift)
	Floppy and SCSI Adapter
Disk	Conner CP30548 (535MB)
	Seagate ST5660NC (535MB)
	Seagate ST31200WC (1.05GB)
	Conner CFP1060E (1.05GB)
	Conner CFP1080E (1.05GB)
	IBM DPES-31080-S1S (1.05GB)
	Quantum 1080S (1.05GB)
	Conner CFP2105E (2.1GB)
	Seagate ST32430WC (2.1GB)
	Seagate ST32550WC (2.1GB)
	IBM DFHS-32160-S2S (2.1GB)
	Seagate ST32155WC (2.1GB)
	IBM DORS-32160 (2.1GB)
	IBM DCAS-32160 (2.1GB)
	Seagate ST32171WC (2.1GB)
	Quantum VK22J05 (2.1GB)
	Seagate ST34371WC (4.2GB)
	Quantum VK45J05 (4.2GB)
	Fujitsu MAB3045SC (4.2GB)
	IBM DDRS-34560 (4.2GB)
Removable Media	Triple Density Floppy Sony MPF520-7-D10 Sony MPF920E
	SunCD 4
	SunCD 12X
	SunCD 32X
	4-8GB 4 mm DDS-2 Tape Drive
	12-24GB 4 mm DDS-3 Tape Drive
	7-14GB 8 mm Tape Drive Exabyte EXB-8505XL Exabyte EXB-8705DX
Ethernet	Quad Ethernet Controller (SQEC/S)
	SunFastEthernet 2.0 / 2.1
	Sun Quad FastEthernet 1.0 (SQFE/S)
	Sun Quad FastEthernet 2.0 (SQFE/S)
	MII to AUI Converter
Communication	SunISDN-BRI/SBI
	Serial Parallel Controller (SPC/S)
	Token Ring Interface (TRI/S)
	High Speed Serial Interface (HSI/S)
	FDDI/S SAS 4.0
	FDDI/S SAS 5.0/6.0
	FDDI/S DAS 5.0/6.0
	SunATM-155/MFiber 2.0/2.1/4.0
	SunATM-155/UTP 2.0/2.1/4.0
	SunATM-622/MFiber 2.1/4.0
Miscellaneous	SunPC Accelerator DX2
	SunPC 133-MHz 5X86
	PCMCIA Adapter
IDPROM	48T59 NVRAM
Boot PROM	U2003
	Sun-4u Flash Update
