| PART # |
DESCRIPTION |
596-5734
380-1214
370-7761
370-7762 [C]
370-7763 [C]
370-7764 [C]
370-7789 [C]
370-7790 |
CT 900 DC Base Chassis (596-5734-01 and -02)
14-Slot 12U 1GB ATCA Chassis/Midplane Assembly
Midplane
Shelf Management Controller/FRU
Power Entry Module/FRU
2-Fan Fan Tray/FRU
LED Controller Board/FRU
14-Slot 12U 1GB ATCA Chassis
|
596-5734
380-1214
370-7762 [C]
370-7763 [C]
370-7764 [C]
370-7789 [C]
380-1554 |
CT 900 DC Base Chassis (596-5734-03)
14-Slot 12U 1GB ATCA Chassis/Midplane Assembly
Shelf Management Controller/FRU
Power Entry Module/FRU
2-Fan Fan Tray/FRU
LED Controller Board/FRU
14-Slot 12U 1GB ATCA Chassis/Midplane
|
596-7084
380-1559 [C]
371-3452 |
CT 900 DC Base Chassis
14-Slot 12U 10GB ATCA Chassis/Midplane Assembly 1
14-Slot 12U 10GB ATCA Chassis/Midplane
|
371-3033 [C]
371-3034 [C]
371-3036 [C]
371-3037 [C]
371-4595 [C] |
2-Fan Fan Tray/FRU
Power Entry Module/FRU
LED Controller Board/FRU
Shelf Management Controller/FRU
Shelf Management Controller/FRU (replacing 371-3037)
|
380-1554 [C]
370-7761
370-7790 |
14-Slot 12U 1GB ATCA Chassis Assembly/Alcatel FRU
Midplane
14-Slot 12U 1GB ATCA Chassis |
|
380-1554 [C] |
14-Slot 12U 1GB ATCA Chassis/Midplane Assembly/Alcatel FRU (380-1554-02)
|
594-1718
375-3282
[C]
594-1548
375-3283
[C] |
Network Switch, Option CP3140H-BEG [S]
Network Switch FRU
Network Switch Rear Transition Module, Option XCP3040H-RTC [S]
Network Switch Rear Transition Module/FRU |
594-4492
375-3507
[C]
594-4493
375-3508
[C] |
Option CP3140H-BEG [S]
(WO_39829 + WO_40155)
1Gbit Network Switch FRU
Option XCP3040H-RTC-ALC [S]
(WO_39829 + WO_40155)
1Gbit Network Switch Rear Transition Module FRU |
594-4492
375-3507
[C]
594-4493
375-3508
[C] |
Alcatel Option CP3140H-BEG-ALC [S]
1Gbit Network Switch FRU
Alcatel Option XCP3040H-RTC-ALC [S]
1Gbit Network Switch Rear Transition Module FRU |
596-5743
341-0742
341-0744 |
Front/Rear Filler Panel
Front Filler Panel
Rear Filler Panel |
594-1549
250-1787 |
Option X4009A [S]
Air Filter (×2) |
594-4767
371-3264 [C] |
Option SG-XPCIE2FC-ATCA-Z
4Gbps Dual Port Fibre Channel Host Bus Adapter |
594-4953
371-3033 [C] |
Option X4058A-Z [S]
CP3020/CP3060 2-Fan Fan Tray/FRU |
594-4784
375-3523
[C] |
Option CP3240H-BEX-Z [S]
10Gbit Ethernet Switch |
594-4786
375-3512
[C] |
Option XCP3240H-RTM-OP-Z [S]
10Gbit Ethernet Optical SFP+ Rear Transition Module |
594-4787
375-3513
[C] |
Option XCP3240H-RTM-CU-Z [S]
10Gbit/1Gbit Copper CX4 Rear Transition Module |
594-4789
375-3514 [C] |
Option XCP32X0-RTM-FC-Z [S] [Blades: CP 3220, CP 3250, CP 3260]
Fibre Channel/Ethernet Advanced Rear Transition Module |
594-4822
375-3544 [C] |
Option XCP32X0-RTM-NT-Z [S] [Blades: CP 3220, CP 3250, CP 3260]
10Gbit Ethernet Advanced Rear Transition Module |
594-4992
375-3550
[C] |
Option XCP3240H-AMC-LED-Z [S]
10Gbit Ethernet LED Advanced Mezzanine Card |
594-6167
375-3608
[C] |
Option XCP3000-AMC-146GB [S]
146GB Disk + x4 PCIe SAS Controller Advanced Mezzanine Card |
594-6657
375-3686 [C] |
Option XCP3000-AMC-300GB [S]
300GB Disk + x4 PCIe SAS Controller Advanced Mezzanine Card |
594-6764
542-0316 [C]
350-1286
540-7867
542-0384
|
Option XCP32X0-RTM-300GBD [S] [Blades: CP 3250, CP 3260, CP 3270]
300GB SAS Disk Assembly
Nemo Bracket Ground Insulator Kit
300GB SAS NEBS Disk Assembly
300GB SAS NEBS Disk Assembly
(E0008821)
|
594-6535
375-3669
375-3667 [C]
542-0316 [C]
350-1286
540-7867
542-0384 |
Option XCP32X0-RTMHD2300D [S] [Blades: CP 3250, CP 3260, CP 3270]
300GB Disk + x4 PCIe SAS Controller Rear Transition Module (RTM)
x4 PCIe SAS2 Controller Rear Transition Module (RTM)
300GB SAS Disk Assembly
Nemo Bracket Ground Insulator Kit
300GB SAS NEBS Disk Assembly
300GB SAS NEBS Disk Assembly
(E0008821)
|
1 Chassis 380-1559 was released as a FRU in May 2013 by E0015953 after EOL.
