7082850	7358668
DDR4-2133 2-Rank/4Gbit SDRAM 1.2V VDD/VDDQ 16GB Registered DIMM Option 7107207	DDR4-2666 1-Rank/8Gbit SDRAM 1.2V VDD/VDDQ 16GB Registered DIMM Option 7119480 (runs at 2133MHz)

7082851	7317930	7326376
DDR4-2133 4-Rank/4GBit SDRAM 1.2V VDD/VDDQ 32GB Load Reduced DIMM Option 7107209	DDR4-2400 2-Rank/8GBit SDRAM 1.2V VDD/VDDQ 32GB Registered DIMM Option 7113004 (runs at 2133MHz)	DDR4-2400 4-Rank/8GBit SDRAM 1.2V VDD/VDDQ 64GB Load Reduced DIMM Option 7114652 (runs at 2133MHz)

SPARC M7 Notes

1. Load Reduced DIMMs and Registered DIMMs can be mixed in the same system.
2. Load Reduced DIMMs and Registered DIMMs can not be mixed on the same CMIOU.

SPARC T7-1 Notes

1. In all configurations, DIMMs must be identical (same size, same rank classification).
2. SPARC T7 and S7 Memory SEEPROM data does not contain a valid Oracle Part Number (Doc ID 2076678.1)

SPARC T7-2 / T7-4 Notes

1. Mixed configurations are supported (DIMMs associated with CM0 with one size, and
   DIMMs associated with CM1 with a different size) as long as all DIMMs in the server have
   the same rank classification.
2. SPARC T7 and S7 Memory SEEPROM data does not contain a valid Oracle Part Number (Doc ID 2076678.1)

References

1. SPARC M7 Series Servers Documentation.
2. SPARC T7-1 Server Documentation.
3. SPARC T7-2 Server Documentation.
4. SPARC T7-4 Server Documentation.
