Memory - SPARC S7-2 / S7-2L

Oracle System Handbook - ISO 7.0 May 2018 Internal/Partner Edition

<a href="../../Systems/SupportHeaders/MEM_SPARC_S7.html">Hmm, you are using a very old browser. Click here to go directly to included content.</a>

7316671 7358611 7316672 7316673

DDR4-2400
2-Rank/4Gbit SDRAM
1.2V VDD/VDDQ
16GB Registered DIMM
Option 7112925 DDR4-2666
2-Rank/8GBit SDRAM
1.2V VDD/VDDQ
16GB Registered DIMM
Option 7119481
(runs at 2400MHz) DDR4-2400
2-Rank/8GBit SDRAM
1.2V VDD/VDDQ
32GB Registered DIMM
Option 7112926 DDR4-2400
4-Rank/8GBit SDRAM
1.2V VDD/VDDQ
64GB Load Reduced DIMM
Option 7113469

S7 Notes

SPARC T7 and S7 Memory SEEPROM data does not contain a valid Oracle Part Number (Doc ID 2076678.1)
