SPARC M6-32 CPU/Memory Unit

7070306	7057504	7070507
CPU Board Assembly CPU Board 7070301 Fruid 7070301	Memory Board Assembly Memory Board 7047493	CPU/Memory Assembly 7070306 + 7057504

Zoom

Quarter Populated Memory

Half Populated Memory

Notes

1. The minimum Solaris 11 OS is Solaris 11.1.
2. The minimum Solaris 10 OS is Solaris 10 1/13 (using Oracle Solaris guest domains).
3. The M6-32 CPU/Memory Unit can be used in the M5-32.
4. All CPU/Memory Units within a DCU must be the same, either M5-32 or M6-32.
5. Do not remove more than one CPU Memory Unit at a time.
6. A fully populated CPU Memory Unit weighs 56Lbs (25.5Kg).

Memory Installation Notes

1. All DIMMs on a CPU Memory Unit must have the same memory capacity.
2. One quarter, one half, and fully populated DIMM configurations are supported.

References

1. SPARC M6-32 Server Documentation.
