cPCI - Dual Differential Ultra SCSI

Codename: Emerald

Option 6749

375-0119
QLogic QCP1042D-SUN 3.3/5V   64Bit   33MHz cPCI

Additional Information & Views

Notes

1. The minimum operating system is Solaris 8 4/01.
2. This board supports basic hot swap and full hot swap.
3. The 68-pin VHDCI connector on Cables 530-2452-01, 530-2453-01, 530-2454-01, and 530-2455-01 is centered in the housing.
4. The 68-pin VHDCI connector on Cables 530-2452-02, 530-2453-02, 530-2454-02, and 530-2455-02 is offset in the housing.
5. Cables with centered VHDCI connectors are not usable at the same time on the A and B ports.
6. Cable 530-2453-02 was released in May 1999. Cables 530-2452-02, 530-2454-02, and 530-2455-02 were released in May 2001.

References

1. Sun StorEdge Ultra1 SCSI cPCI Differential HBA, Dual port Documentation.
