8-Port 6Gbps SAS-2 HBA

Codename: Erie-INT

Option SGX-SAS6-INT-Z

375-3640	7047852
LSI H3-25104-xx x8 PCI Express	LSI H3-25104-xx x8 PCI Express

Additional Information & Views

Notes

1. The 8-Port SAS HBA was released in March 2010. (WO_42751)
2. The minimum Solaris OS is Solaris 10 10/09 per 820-7889-10 of July 2010.
3. The recommended minimum Solaris OS is Solaris 10 01/13 per E22494-05 of September 2013.
4. For the latest recommended OS support levels, see the Installation Guide.
5. PCI Identifiers are Vendor ID 0x1000, Device ID 0x0072, and Subsystem ID 0x3050.
6. Vital Product Data VPD=PN is 375-3640 for both part numbers.

References

1. Sun Storage 6 Gb SAS PCIe HBA, Internal Documentation
2. Sun Engineering Specification, 950-6032.
