Notes

1. The minimum UltraSPARC III operating system is Solaris 8 4/01.
2. The minimum UltraSPARC IV operating system is Solaris 8 2/04 or Solaris 9 4/04.
3. Repeater Board slots are labeled RP0 through RP3.
4. Repeater Board Filler 540-4042 is not ECO released.
5. L2 Repeater 501-4953 is not qualified in the E4900 and E6900.

FRU Notes

1. F501-4953-08 and -09 included L2 Repeater 501-4953.
2. F501-4953-10 Rev 50 (February 2003) included L2 Repeater 501-6418.
3. F501-4953-10 Rev 51 (April 2003) includes L2 Repeater 501-4953.
4. F501-6418 (April 2003) includes L2 Repeater 501-6418.

References

1. Sun Fire 4800 Server Documentation.
2. Sun Fire 4810 Server Documentation.
3. Sun Fire 6800 Server Documentation.
4. Sun Fire E4900 Server Documentation.
5. Sun Fire E6900 Server Documentation.

Notes

1. The minimum UltraSPARC III operating system is Solaris 8 4/01.
2. The minimum UltraSPARC IV operating system is Solaris 8 2/04 or Solaris 9 4/04.
3. The minimum UltraSPARC IV+ operating system is Solaris 9 9/05 or Solaris 10 3/05 HW1.
4. Repeater Board slots are labeled RP0 through RP3.
5. L2 Repeater 501-7231 ships in the Sun Fire E4900 (post July 2006) and E6900 (post July 2006).

References

1. Sun Fire 4800 Server Documentation.
2. Sun Fire 4810 Server Documentation.
3. Sun Fire 6800 Server Documentation.
4. Sun Fire E4900 Server Documentation.
5. Sun Fire E6900 Server Documentation.

Notes

1. The minimum UltraSPARC III operating system is Solaris 8 4/01.
2. The minimum UltraSPARC IV operating system is Solaris 8 2/04 or Solaris 9 4/04.
3. The minimum UltraSPARC IV+ operating system is Solaris 9 9/05 or Solaris 10 3/05 HW1.
4. Repeater Board slots are labeled RP0 through RP3.
5. L2 Repeater 501-7594 supports multiple domains in Sun Fire 6800 and E6900.
6. L2 Repeater 501-7594 requires OBP 5.20.1.
7. XE6900-FP-SWITCH-Z includes four 501-7594 L2 Repeaters. OBP 5.20.1 is required.
8. The SC showboards command identifies 501-7594 as Repeater Board V2.
9. Do not mix 501-4953, 501-6418, or 501-7231 with 501-7594.

References

1. Sun Fire 4800 Server Documentation.
2. Sun Fire 4810 Server Documentation.
3. Sun Fire 6800 Server Documentation.
4. Sun Fire E4900 Server Documentation.
5. Sun Fire E6900 Server Documentation.
