PCI Express Riser

<a href="../../Systems/SupportHeaders/IO_Netra_T3_1_PCI_Expr_Riser.html">Hmm, you are using a very old browser. Click here to go directly to included content.</a>

371-4944 371-4945 371-4946 542-0382

Riser 0
Assembly R0350-F0014-0
Bracket R0350-F0040-01
PCB R0350-G0001-02 Riser-1
Assembly R0350-F0015-01
Bracket R0350-F0041-01
PCB R0350-G0002-02 Riser-2
Assembly R0350-F0016-01
Bracket R0350-F0042-01
PCB R0350-G0003-02 Riser FRU
Riser 0, 1, and 2

7052372 7052373 7052390 7052388

Riser 0
Assembly R0350-F0014-01
Bracket R0350-F0040-01
PCB R0350-G0001-02 Riser-1
Assembly R0350-F0015-01
Bracket R0350-F0041-01
PCB R0350-G0002-02 Riser-2
Assembly R0350-F0016-01
Bracket R0350-F0042-01
PCB R0350-G0003-02 Riser FRU
Riser 0, 1, and 2

Riser-0 371-4944 and 7052372

Riser-1 371-4945 and 7052373

Riser-2 371-4946 and 7052390

Netra SPARC T3-1 Codename: Madrid
Netra SPARC T4-1 Codename: MadridT4-1
