XVR-600 Graphics Accelerator

Codename: IFB3 Lite+/Jaguar Lite

24-Bit Color Frame Buffer

Workstations:	Sun Blade 150, 1500, 2500
Servers:	Sun Fire V120, V210, V240, V250, V440, V480, V490, V880, V890
Telco:	Netra 20, 240

Options 3780 / 5411 / 5412

375-3153
3.3/5V 64Bit 33/66MHz

Additional Information & Views

UNIX ID: /dev/fbs/jfb0

Notes

1. The minimum OS is Solaris 8 2/02 plus the XVR-600 Installation CD.
2. Solaris 8 patch 114554-20 or Solaris 9 patch 114555-20 is required.
3. OpenGL for Solaris requires between 65-110Mbytes of disk space.
4. OpenGL 1.3 for Solaris requires Patch >/= 113886-10 (32-bit) or >/= 113887-10 (64-bit).
5. Patch >/= 113886-26 or >/= 113887-26 for BugID 15225455 [SUNBT5095048] is recommended in FIN I1161-1.
6. OpenGL 1.2.3 for Solaris requires Patch >/=112628-20 (32-bit) or >/=112629-20 (64-bit).
7. Option 3780 includes DVI-A(M) to DB13W3(F) Adapter 530-3170.
   If applicable, the DVI-A(M) to HD15(M) Adapter Cable is 530-3171.
8. An empty slot is required between every XVR-600 installed in the Sun Fire V480.

Reference

1. fbconfig (1M) manual page.
2. Sun XVR-600 Graphics Accelerator Documentation.
