Dual 16Gigabit/Sec Fibre Channel / 10Gigabit/Sec FCoE HBA Module

Codename: Ganymede-Q

Option 7101682

7023304
Qlogic QEM8362-ORL-BK x8 PCI Express Gen1/Gen2/Gen3

Additional Information & Views

Notes

1. Mixing Transceiver types is not supported. Use 16Gbps SFP+ or 10Gbps SFP+.
2. The 10Gbps SFP+ and 16Gbps SFP+ transceivers are sold and FRU'd as pairs.
3. Use 10Gbps Shortwave SFP+ 7023316, FRU Pair 7023315, Option 7101678.
4. Use 16Gbps Shortwave SFP+ 7023324, FRU Pair 7023325, Option 7101676.
5. Use 16Gbps Longwave SFP+ 7023064, FRU Pair 7023066, Option 7101680.
6. Fibre Channel PCI Identifiers are Vendor ID 0x1077 and Device ID 0x0231.
7. Ethernet PCI Identifiers are Vendor ID 0x1077 and Device ID 0x8030.
8. FCoE PCI Identifiers are Vendor ID 0x1077 and Device ID 0x8031.
9. Vital Product Data VPD=PN is 7023304.

References

1. Sun Storage 16 Gb FC PCIe Universal HBA Documentation For HBA Model 7101682.
