Seagate ST373307FC (73.4GB)

3 1/2" 10000 RPM FC-AL

Options 6713 / 6742 / 6756 / 6766 / 6805 / 6807 / 6808 / 6815 / 6855

390-0115 390-0121 540-4519
Cheetah 10K.6
1" Height
Assembly 540-4519		 Cheetah 10K.6
1" Height
Assy 540-4905
Assy 540-5330
Assy 540-5408
Assy 540-5629
Assy 540-5694
Assy 540-6240		 T3 FRU
w Bracket 540-4303
Option 6713
540-4905 540-5330 540-5408
Spud Bracket FRU
w 1" Bracket 540-3024
w Plate 340-6640
or Plate 340-7269		 SE6020/6120 FRU
w 1" Bracket 540-4863
Option 6815A
See Notes		 Spud Bracket FRU
w 1" Bracket 540-3024
w Plate 340-6640
or Plate 340-7269
540-5629 540-5694 540-6240
SE3510 FRU
w 1" Bracket
XTA-3510-73GB-10K
See Notes		 NEBS Level 3 FRU
w 1" Bracket 540-3024
w Plate 340-6640
or Plate 340-7269		 SE6130 FRU
w 1" Bracket
XTA-FC1CD-73G10K

Notes

  1. Drives 390-0115 and 390-0121 (released in October 2002) have different firmware.
  2. Assembly 540-5408 was released in April 2002. (WO_23948)
  3. Drive 390-0121 was added to Assembly 540-5408 in October 2002. (WO_25053)
  4. Assembly 540-5408 with 390-0121 failed Netra 20 ESD testing.
  5. Netra 20 73GB Assembly 540-5694 was released in December 2002. (WO_25452)
  6. Drive 390-0121 was added to Assembly 540-5694 in March 2003. (WO_26062)
  7. Drive 390-0121 was removed from Assembly 540-5330 in March 2005. (WO_30780)
  8. Drive 390-0121 was removed from Assembly 540-5629 in April 2005. (WO_30974)
  9. Drive 390-0121 was removed from Assemblies 540-4519, 540-4905, 540-5408, 540-5694, and 540-6240 in June 2006. (WO_32355)

References

  1. 73 Gbyte 10000 rpm Disk Drive Specifications, 816-1113 (except T3).
  2. 73 Gbyte 10000 rpm Disk Drive Specifications, 806-4800 (T3/T3+ only).
