Seagate ST373207FC (73.4GB)

3 1/2" 10000 RPM FC-AL

Options 6713 / 6742 / 6756 / 6766 / 6805 / 6807 / 6808 / 6815
Option XTA-3510-73GB-10K
Option XTA-FC1CD-73G10K

390-0165 390-0168 540-4519 540-4905
Cheetah 10K.7
1" Height
Assembly 540-4905
Assembly 540-5330
Assembly 540-5408
Assembly 540-6240		 Cheetah 10K.7
1" Height
T3 Firmware
Assembly 540-4519		 T3 FRU
w Bracket 540-4303
Option 6713		 Spud Bracket FRU
w 1" Bracket 540-3024
w Plate 340-6640
or Plate 340-7269
540-5330 540-5408 540-5629 540-6240
SE6020/6120 FRU
w 1" Bracket 540-4863
Option 6815		 Spud Bracket FRU
w 1" Bracket 540-3024
w Plate 340-6640
or Plate 340-7269		 SE3510 FRU
w 1" Bracket
XTA-3510-73GB-10K		 SE6130 FRU
w 1" Bracket
XTA-FC1CD-73G10K

Notes

  1. Drives 390-0165 and 390-0168 (released in March 2005) have different firmware. (WO_30780)
  2. Drive 390-0165 was removed from Assembly 540-6240 in March 2005. (WO_30863)
  3. Drive 390-0165 was added to Assembly 540-5629 in April 2005. (WO_30867)
  4. Drive 390-0165 was added to Assembly 540-6240 in August 2005. (WO_31554)
  5. XTA-3510-73GB-10K changed from 540-5629 to 540-6570 in October 2006. (WO_34374)


Seagate ST373207FC (73.4GB)

3 1/2" 10000 RPM FC-AL

Options 6713 / 6742 / 6756 / 6766 / 6805 / 6807 / 6808 / 6815
Option XTA-3510-73GB-10K
Option XTA-FC1CD-73G10K

390-0278 390-0279 540-4519
Cheetah 10K.7
1" Height
T3 Firmware
Assembly 540-4519		 Cheetah 10K.7
1" Height
Assembly 540-4905
Assembly 540-5330
Assembly 540-5408
Assembly 540-6240
Assembly 540-6604		 T3 FRU
w Bracket 540-4303
Option 6713
540-4905 540-5330 540-5408
Spud Bracket FRU
w 1" Bracket 540-3024
w Plate 340-6640
or Plate 340-7269		 SE6020/6120 FRU
w 1" Bracket 540-4863
Option 6815		 Spud Bracket FRU
w 1" Bracket 540-3024
w Plate 340-6640
or Plate 340-7269
540-5629 540-6240 540-6570 540-6604
SE3510 FRU
w 1" Bracket
XTA-3510-73GB-10K		 SE6130 FRU
w 1" Bracket
XTA-FC1CD-73G10K		 SE3510 FRU
w 1" Bracket
XTA-3510-73GB-10K		 Spud Bracket FRU
w 1" Bracket 540-3024
w Plate 341-1986

Notes

  1. Drives 390-0278 and 390-0279 were released in September 2005. (WO_31694)
  2. Drive 390-0278 was added to 540-4519 in November 2005. (WO_31953)
  3. Drive 390-0279 was added to 540-4905, 540-5330, 540-5408, 540-5629, and 540-6240 in November 2005. (WO_31953)
  4. Assembly 540-6604 with 390-0279 was released in December 2005. (WO_31926)
  5. Option 6805 changed from 540-5408 to 540-6604 in January 2006. (WO_32023)
  6. Assembly 540-6570 with 390-0279 was released in March 2006. (WO_32667)
  7. XTA-3510-73GB-10K changed from 540-5629 to 540-6570 in October 2006. (WO_34374)
