Seagate ST336607FC (36.4GB)
3 1/2" 10000 RPM FC-AL
Options 6706 / 6714 / 6724 / 6751 / 6819
| 390-0137 |
390-0138 |
Cheetah 10K.6
1" Height
Assembly 540-4525
Assembly 540-5698 |
Cheetah 10K.6
1" Height
Assembly 540-4367 |
| 540-4367 |
540-4525 |
540-5698 |
T3 FRU
w Bracket 540-4303 |
Spud Bracket FRU
w 1" Bracket 540-3024
w Plate 340-6640
or Plate 340-7269 |
NEBS Level 3 FRU
w 1" Bracket 540-3024
w Plate 340-6640
or Plate 340-7269 |
Notes
- Drives 390-0137 and 390-0138 (released in October 2002) have different
firmware.
- Assembly 540-4525 was released in August 2000.
- Drive 390-0137 was added to Assembly 540-4525 in October 2002.
- Assembly 540-4525 with 390-0137 failed ESD testing in the Netra 20.
- Netra 20 36GB Assembly 540-5698 (released in December 2002)
includes 390-0137 as of March 2003.
References:
36 Gbyte 10000 rpm Disk Drive Specifications, 806-4799 (except T3).
-
36 Gbyte 10000 rpm Disk Drive Specifications, 806-6383 (T3/T3+ only).
|
