Seagate ST318404LC (18.2GB)

3 1/2" 10000 RPM Single Ended Ultra-1 SCSI

<a href="../../Systems/SupportHeaders/DISK_Sgte_ST318404LC.html">Hmm, you are using a very old browser. Click here to go directly to included content.</a>

Options 5164 / 5237 / 5238 / 5239 / 5247 / 5880

390-0038
1" Height Cheetah 18XL

540-4177	540-4401	540-4921
Spud Bracket FRU w 1" Bracket 540-3024	Netra ct/st/T1 FRU NEBS Level 3 w 1" Bracket 540-3024 w Plate 340-4288 or 340-6640 or Plate 340-5928 or 340-7269	Netra t1 NEBS FRU w 1" Bracket 540-3024

540-4178	595-5471
StorEdge D240 Center FRU 12-Slot A1000/D1000 FRU w 1" Bracket 540-3024 w Plate 340-4288 or 340-6640 or Plate 340-5928 or 340-7269	StorEdge D240 Left/Right FRU Assembly 599-2398 or Assembly 540-5701 w Drive 540-4177 w Bracket 340-6476

Notes

The LVD capability of this drive is not qualified by Sun.
The 160Mbyte/sec capability of this drive is not qualified by Sun.
Drive 390-0038 was shipped in 540-4401 by deviation WO_20568 .
Drive 390-0038 is not qualified for use in the Netra st A1000/D1000.
