Seagate ST3146855LC (146.8GB)

3 1/2" 15000 RPM Low Voltage Differential Ultra-320 SCSI

Option X4154A-Z
Option XRA-SC1NB-146G15K
Option XTA-SC1NC-146G15K
Option XTA-SC1CH-146G15K
Option XRA-SC1CB-146G15KZ

390-0327
1" Height
Cheetah 15K.5
371-2606 540-6461 540-6494 540-6607
V40z FRU
1" Bracket
X4154A-Z		 Spud Bracket FRU
w 1" Bracket 540-3024
w Plate 341-1986		 3120/3320 FRU
1" Bracket
XTA-SC1NC-146G15K		 Netra 240/440 FRU
NEBs Level 3
w 1" Bracket 540-3024
w Plate 341-1986
540-7316
StorEdge D240
Left/Right FRU
Bracket 340-6476
XTA-SC1CH-146G15K

Notes

  1. Drive 390-0205 was released and added to 540-6461 and 540-6484 in March 2007. (WO_35146)
  2. Drive 390-0327 was released in June 2007. (WO_35358)
  3. Drive 390-0327 was added to 540-6494 in June 2007. (WO_36977)
  4. The Seagate model number on the serial number label is ST3146855LC.
  5. The Sun model number on the serial number label is ST314655LSUN146G.
  6. The Product Identification in SCSI Inquiry bytes 16-31 is ST314655LSUN146G.

D240 Notes

  1. Assembly 540-7316 with 390-0327 was released in June 2007. (WO_35358)
  2. Drive 390-0327 was removed from 540-7316 in December 2007. (WO_38339)

V40z Notes

  1. V40z part number 371-2606 was released in February 2007. (WO_33464)
  2. ST3146855LC was added as an alternate for 371-2606 in February 2007. (CW_01028)


Seagate ST3146855LC (146.8GB)

3 1/2" 15000 RPM Low Voltage Differential Ultra-320 SCSI

Disk Arrays: StorEdge D240

Option XTA-SC1CB-146G15K
Option XTA-SC1CH-146G15K

390-0416
1" Height
Cheetah 15K.5
540-7316 540-7591
StorEdge D240
Left/Right FRU
Bracket 340-6476
XTA-SC1CH-146G15K		 Spud Bracket FRU
1" Bracket 540-3024
Plate 341-1986
XTA-SC1CB-146G15K

Notes

  1. Drive 390-0416 was released in April 2008. (WO_38951)
  2. Drive 390-0416 was added to 540-7316 and 540-7591 in April 2008. (WO_38951)
  3. Drive 390-0416 includes firmware unique to the StorEdge D240.
  4. Drive 390-0416 and 390-0327 are the same Seagate model with different firmware.
  5. The Seagate model number on the serial number label is ST3146855LC.
  6. The Sun model number on the serial number label is ST314A55LSUN146G.
  7. The Product Identification in SCSI Inquiry bytes 16-31 is ST314A55LSUN146G.
