Hitachi HUS103014FL3800 (146.8GB)

3 1/2" 10000 RPM Low Voltage Differential Ultra-320 SCSI

Options 5268 / 5269 / 9257 / 9892
Option XTA-3310-146GB-10K
Option XTA-SC1NC-146G10K
Option XRA-SC1CA-146G10K
Option XRB-SC1CA-146G10K

390-0179
Ultrastar 10K300
1" Height
540-5735 540-6058 540-6065 540-6369
3300 Series FRU
1" 3300 Bracket
Plate 340-7269		 3100 Series FRU
1" 3100 Bracket		 Spud Bracket FRU
1" Bracket 540-3024		 Spud Bracket FRU
1" Bracket 540-3024
XRB-SC1CA-146G10K
540-6064 540-6123
StorEdge D240
Center FRU
Spud Bracket FRU
1" Bracket 540-3024
Plate 340-7269		 StorEdge D240
Left/Right FRU
Drive Assembly 540-6065
Bracket 340-6476

Notes

  1. Drive 390-0179 was released in June 2005. (WO_31257)
  2. The Sun Model Number on the serial number label is HUS10143ASUN146G.
  3. XTA-3310-146GB-10K changed from 540-5735 to 540-6450 in October 2006. (WO_34374)


Hitachi HUS103014FL3800 (146.8GB)

3 1/2" 10000 RPM Low Voltage Differential Ultra-320 SCSI

Options 5268 / 5269 / 9257 / 9892
Option XTA-3310-146GB-10K
Option XTA-SC1NC-146G10K
Option XRA-SC1CA-146G10K
Option XRB-SC1CA-146G10K
Option XRA-SC1CB-146G10K
Option XRA-SC1CC-146G10K

390-0266
Ultrastar 10K300
1" Height
540-5735 540-6058 540-6065 540-6227
3300 Series FRU
1" 3300 Bracket
Plate 340-7269		 3100 Series FRU
1" 3100 Bracket		 Spud Bracket FRU
1" Bracket 540-3024		 V60x/V65x FRU
5210 NAS FRU
1" Bracket 330-3696
540-6369 540-6450 540-6601 540-6602
Spud Bracket FRU
1" Bracket 540-3024
XRB-SC1CA-146G10K		 3120/3310/3320 FRU
1" Bracket
XTA-SC1NC-146G10K
(From 10/26/05)
XTA-3310-146GB-10K		 Spud Bracket FRU
1" Bracket 540-3024		 Spud Bracket FRU
1" Bracket 540-3024
Plate 341-1986
540-6064 540-6123
StorEdge D240
Center FRU
Spud Bracket FRU
1" Bracket 540-3024
Plate 340-7269		 StorEdge D240
Left/Right FRU
Drive Assembly 540-6065
Bracket 340-6476

Notes

  1. Drive 390-0266 was released in October 2005. (WO_31849)
  2. The Sun Model Number on the serial number label is HUS10143ASUN146G.
  3. Assembly 540-6450 with 390-0266 was released in October 2005. (WO_31708)
  4. XTA-SC1NC-146G10K changed from 540-6058 to 540-6450 in October 2005. (WO_31505)
  5. Drive 390-0266 was added to 540-5735, 540-6058, 540-6064, 540-6065, 540-6227, and 540-6369 in November 2005. (WO_32024)
  6. Assembly 540-6601 with 390-0266 was released in December 2005. (WO_31926)
  7. Assembly 540-6602 with 390-0266 was released in December 2005. (WO_31926)
  8. Option 5268 changed from 540-6065 to 540-6601 in January 2006. (WO_32023)
  9. XRA-SC1CA-146G10K changed from 540-6065 to 540-6601 in January 2006. (WO_32023)
  10. XTA-3310-146GB-10K changed from 540-5735 to 540-6450 in October 2006. (WO_34374)
