Fujitsu MAT3073NC (73.4GB)

3 1/2" 10000 RPM Low Voltage Differential Ultra-320 SCSI

Options 5245 / 5263 / 5264 / 5265 / 5886 / 9256
Options XRA-SC1CA-73G10K / XRA-SC1CB-73G10K
Options XTA-SC1NC-73G10K / XTA-3310-73GB-10K
390-0175
1" Height
Allegro 9LE
CA06350-B1xx
370-6689 371-0292 540-5456 540-5563
V20z/V40z FRU
1" Bracket
9256A		 V20z/V40z FRU
1" Bracket
9256A		 Spud Bracket FRU
1" Bracket 540-3024		 3300 Series FRU
1" 3300 Bracket
XTA-3310-73GB-10K
540-5771 540-5937 540-6056 540-6289
CT 410/810 FRU
N120/N1280/V120 FRU
NEBS Level 3
1" Bracket 540-3024
Plate 340-5928
Plate 340-7269
or Plate 341-1986		 V60x/V65x FRU
1" Bracket 330-3696		 3100 Series FRU
1" 3100 Bracket
XTA-SC1NC-73G10K		 Spud Bracket FRU
1" Bracket 540-3024
XRA-SC1CA-73G10K
540-5455 540-5652
StorEdge D240
Center FRU
Spud Bracket FRU
1" Bracket 540-3024
Plate 340-5928
Plate 340-7269
or Plate 341-1986		 StorEdge D240
Left/Right FRU
Assy 599-2652
or Assy 540-5703
Drive 540-5456
Bracket 340-6476

Notes

  1. Drive 390-0175 was released in December 2004. (WO_30261)
  2. The MAT3073NC was added as an alternate source for 370-6689 in March 2005.
  3. The MAT3073NC on Solaris 10 3/05 x86 requires Patch 119375. (see 819-2501-10)
  4. Drive 390-0175 was added to 540-5937 in June 2005. (WO_31072)
  5. Part number 371-0292 was released in January 2006. (WO_32203)
  6. XTA-3310-73GB-10K changed from 540-5563 to 540-6448 in October 2006. (WO_34374)
