Fujitsu MAP3735NC (73.4GB)

3 1/2" 10000 RPM Low Voltage Differential Ultra-320 SCSI

Options 5263 / 5264

390-0107 540-5456
1" Height
Allegro 8LE
CA06200-B2xx
46 Byte Inquiry
TEC485-2405331		 Spud Bracket FRU
w 1" Bracket 540-3024
540-5455 540-5652
StorEdge D240
Center FRU
Spud Bracket FRU
w 1" Bracket 540-3024
w Plate 340-5928
or Plate 340-7269
or Plate 341-1986		 StorEdge D240
Left/Right FRU
Assembly 599-2652
or Assembly 540-5703
Drive 540-5456
w Bracket 340-6476

Notes

  1. Drive 390-0107 was released in March 2003.
  2. The Netra CT 410/810 shipped with 540-5455 and 540-5771.
  3. 540-5771 replaced 540-5455 in the Netra CT 410/810 in February 2003.
  4. Drive 390-0107 was added to Assembly 540-5455 in March 2003.
  5. Drive 390-0107 was not tested in the Netra CT 410/810.
  6. Drive 390-0157 replaced 390-0107 in Assembly 540-5455 in May 2003.
  7. Drive 390-0157 replaced 390-0107 in Assembly 540-5456 in May 2003.
  8. Drive 390-0107 was discontinued prior to announcement of 73GB support in the Netra 1280 and Sun Fire V1280.


Fujitsu MAP3735NC (73.4GB)

3 1/2" 10000 RPM Low Voltage Differential Ultra-320 SCSI

Options 5245 / 5263 / 5264 / 5265 / 5886 / 7205
Option XTA-3310-73GB-10K
Option XTA-3310-73GB-10KL
Options XRA-SC1CB-73G10K / XTA-SC1NC-73G10K
Option XRA-SC1CA-73G10K

390-0157
1" Height
Allegro 8LE
CA06200-B2xx
96 Byte Inquiry
TEC485-2405361
370-6689 371-0292 540-5456
V20z/V40z FRU
1" Bracket / 73.5GB
9256A		 V20z/V40z FRU
1" Bracket / 73.5GB
9256A		 Spud Bracket FRU
w 1" Bracket 540-3024
540-5563 540-5771 540-6056
3300 Series FRU
1" 3300 Bracket
XTA-3310-73GB-10K		 CT 410/810 FRU
N120/N1280/V120 FRU
NEBS Level 3
w 1" Bracket 540-3024
w Plate 340-5928
or Plate 340-7269
or Plate 341-1986		 3100 Series FRU
1" 3100 Bracket
XTA-SC1NC-73G10K
540-6286 540-6289 565-1569
3300 Series FRU
1" 3300 Bracket
XTA-3310-73GB-10KL
Lucent Technologies		 Spud Bracket FRU
w 1" Bracket 540-3024
not V440 qualified
XRA-SC1CA-73G10K		 12K/15K SC Peripheral Bd
>= 565-1569-04
540-5455 540-5652
StorEdge D240
Center FRU
Spud Bracket FRU
w 1" Bracket 540-3024
w Plate 340-5928
or Plate 340-7269
or Plate 341-1986		 StorEdge D240
Left/Right FRU
Assembly 599-2652
or Assembly 540-5703
Drive 540-5456
w Bracket 340-6476

Notes

  1. Drive 390-0157 was released in May 2003.
  2. The Netra CT 410/810 shipped with 540-5455 and 540-5771.
  3. 540-5771 replaced 540-5455 in the Netra CT 410/810 in February 2003.
  4. Drive 390-0157 was added to Assembly 540-5455 in May 2003.
  5. Drive 390-0157 was added to Assembly 540-5771 in July 2003.
  6. Drive 390-0157 was not tested in the Netra CT 410/810 until July 2003.
  7. The MAP3735NC was added an alternate source for 370-6689 in September 2004.
  8. The MAP3735NC 370-6689 changed to 371-0292 in January 2006. (WO_32203)
  9. XTA-3310-73GB-10K changed from 540-5563 to 540-6448 in October 2006. (WO_34374)
