Fujitsu MAJ3364MC (36.4GB)

3 1/2" 10000 RPM Single Ended Ultra-1 SCSI

<a href="../../Systems/SupportHeaders/DISK_Fuj_MAJ3364MC.html">Hmm, you are using a very old browser. Click here to go directly to included content.</a>

Options 5242 / 5243 / 5244 / 5249 / 5257 / 5884

390-0051	390-0059
1" Height Allegro 6	1" Height Allegro 6 UniPack Drive
540-4521	540-4689
Spud Bracket FRU w Drive 390-0051 w 1" Bracket 540-3024	Netra ct/st/CT/T1/120 FRU NEBS Level 3 w 1" Bracket 540-3024 w Plate 340-4288 or 340-6640 or Plate 340-5928 or 340-7269
540-4919	540-5693
Netra t1/t1400/1405 NEBS FRU w Drive 390-0051 w 1" Bracket 540-3024	Netra t1400/1405 FRU NEBS Level 3 w Drive 390-0051 w 1" Bracket 540-3024
540-4520	595-6394
StorEdge D240 Center FRU 12-Slot A1000/D1000 FRU w 1" Bracket 540-3024 w Plate 340-4288 or 340-6640 or Plate 340-5928 or 340-7269	StorEdge D240 Left/Right FRU Assembly 599-2593 or Assembly 540-5702 Drive 540-4521 w Bracket 340-6476

Notes

The LVD capability of this drive is not qualified by Sun.
The 160Mbyte/sec capability of this drive is not qualified by Sun.
Drives 390-0051 and 390-0059 are the same Fujitsu model number.
Drives 390-0051 and 390-0059 respond to a SCSI Inquiry command with different values.

Reference

36 Gbyte 10000 rpm Disk Drive Specifications, 806-4798.
