Fujitsu MAJ3182MC (18.2GB)

3 1/2" 10000 RPM Single Ended Ultra-1 SCSI

<a href="../../Systems/SupportHeaders/DISK_Fuj_MAJ3182MC.html">Hmm, you are using a very old browser. Click here to go directly to included content.</a>

Options 5164 / 5237 / 5238 / 5239 / 5247 / 5880 / 6957

390-0043	390-0060	540-4077	540-4177
1" Height Allegro 6LE	1" Height Allegro 6LE UniPack Drive	ft 1800 FRU w Bracket 540-4884 w Plate 340-4288 or Plate 340-6640	Spud Bracket FRU w Drive 390-0043 w 1" Bracket 540-3024

540-4401	540-4921	565-1569
Netra ct/st/T1 FRU NEBS Level 3 w Drive 390-0043 w 1" Bracket 540-3024 w Plate 340-4288 or Plate 340-6640 or Plate 340-5928 or Plate 340-7269	Netra t NEBS FRU w Drive 390-0043 w 1" Bracket 540-3024	12K/15K SC Peripheral Bd <= 565-1569-03

540-4178	595-5471
StorEdge D240 Center FRU 12-Slot A1000/D1000 FRU w Drive 390-0043 w 1" Bracket 540-3024 w Plate 340-4288 or 340-6640 or Plate 340-5928 or 340-7269	StorEdge D240 Left/Right FRU Assembly 599-2398 or Assembly 540-5701 w Drive 540-4177 w Bracket 340-6476

Notes

The LVD capability of this drive is not qualified by Sun.
The 160Mbyte/sec capability of this drive is not qualified by Sun.
Drives 390-0043 and 390-0060 are the same Fujitsu model number.
Drives 390-0043 and 390-0060 respond to an Inquiry command with different values.

References

18 Gbyte Disk Drive Specifications, 806-1057.
18 Gbyte Disk Drive Specifications, 806-6395.
