Fujitsu MAG3182LC (18.2GB)

3 1/2" 10000 RPM Single Ended Ultra-1 SCSI

<a href="../../Systems/SupportHeaders/DISK_Fuj_MAG3182LC.html">Hmm, you are using a very old browser. Click here to go directly to included content.</a>

Options 5164 / 5237 / 5238 / 5880 / 6957

390-0006
1" Height Allegro 5

540-4077	540-4177
Netra ft 1800 FRU w Bracket 540-4884 w Plate 340-4288 or Plate 340-6640	Spud Bracket FRU w 1" Bracket 540-3024
540-4178	595-5471
StorEdge D240 Center FRU 12-Slot A1000/D1000 FRU w 1" Bracket 540-3024 w Plate 340-4288 or 340-6640 or Plate 340-5928 or 340-7269	StorEdge D240 Left/Right FRU Assembly 599-2398 or Assembly 540-5701 w Drive 540-4177 w Bracket 340-6476

Notes

The LVD capability of this drive is not qualified by Sun.
The 40/80Mbyte/sec capability of this drive is not qualified by Sun.
This drive is not NEBS Level 3 qualified in the Netra st D130.
