Type A208
450 Watt Power Supply

<a href="../../Systems/SupportHeaders/DCPOWER_Tyco_1817_450W.html">Hmm, you are using a very old browser. Click here to go directly to included content.</a>

F300-1735

300-1735	300-1817	300-2110
Power One Type A208 AC Input Power Supply March 2006	Tyco Type A208 AC Input Power Supply March 2006	Astec DS450HE AC Input Power Supply May 2007

AC Input

100-240Vac

50-60Hz

6A RMS Max

DC Output

+12V	+3.3Vsb
36.6A	3.1A

Efficiency

220V	100% Load	>=88%
220V	75% Load	>=88%
220V	50% Load	>=84%
220V	30% Load	>=84%

Sun Fire T2000 Codename: Ontario
SPARC Enterprise T2000 Codename: Ontario APL

Notes

Power Supply Efficiency affects the current draw in AC Watts from the branch circuit.
As efficiency increases, the current draw in AC Watts decreases.
To calculate maximum theoretical current draw in AC Watts, multiply the maximum power supply output in DC Watts by the reciprocal of the power supply efficiency.
Theoretical values are typically higher than published values which are based on measured outputs under controlled test conditions.
