Oracle System Handbook - ISO 7.0 May 2018 Internal/Partner Edition

Power One HB-PCM01-580-AC
580 Watt Power Supply

<a href="../../Systems/SupportHeaders/DCPOWER_PowerOne_7043627_580W.html">Hmm, you are using a very old browser. Click here to go directly to included content.</a>

7043627 7345278

AC Input Power Supply AC Input Power Supply
India ISI Mark

AC Input

100-240Vac

50-60Hz

8A Max

DC Output

+5V	+12	+5Vsb
42A	38A	52.0A

Notes

Part Numbers (P/N) labeled on the rear of the power supply and on the handle are not Oracle
part numbers. The Oracle part number is behind the compliance label.
