Astec AA22780
400 Watt Power Supply
| 300-1567 |
300-1845 |
Type D158
DC Input Power Supply
System Specification 950-4001 |
Type D158
DC Input Power Supply
System Specification 950-4001 |
DC Input
DC Output
| +3.3V |
+5V |
+12V |
-12V |
+5VSB |
| 20.3A |
17.2A |
25.0A |
0.42A |
2.8A |
Netra 240 Codename: Enchilada 19
Netra 440 Codename: Chalupa 19 |
Notes
- The +12V output is labeled 23.0A on the Power Supply.
- The +12V output is rated 25.0A in Sun Specification 950-4001-01.
- The combined output of +3.3, +5, and +12 can not exceed 381 Watts.
|
