Oracle System Handbook - ISO 7.0 May 2018 Internal/Partner Edition

AcBel FS7013-470G
530 Watt Power Supply

<a href="../../Systems/SupportHeaders/DCPOWER_AcBel_2132_530W.html">Hmm, you are using a very old browser. Click here to go directly to included content.</a>

300-2132

AC Input Power Supply
No Specification

AC Input

100-240V

50-60Hz

8A-4A

DC Output

+3.3V	+5V	+12V₁	+12V₂	+5V_sb	-12V
14A	20A	18A	17A	3.0A	0.5A

Maximum combined output of +3.3 and +5 is 146 Watts
Maximum combined output of +12 is 276 Watts
Efficiency is 80% with 100% load
The Power Supply is not labeled with a FRU part number.

Ultra 24 Codename: Ursa
Ultra 27 Codename: Volans
